HIGH SPEED COOK OVEN, MERRYCHEF

Code:
MO-CONNEX 16 HP
Stock Level:
Our Price
$29,396.00
Add to Favourites

Add To Quote

Compare Product
View Compare List View Enquiry List Go to Checkout
Contact for Purchase Options
Description

Description

conneX a new talent in the kitchen. The next gen high-speed oven

Compact, sleek, and stylish to fit anywhere. The new conneX high-speed oven range came fully trained and ready for action! The easyTouch 2.0 icon-driven controller has a high-definition 7" widescreen display and the capacitive touchscreen works as smoothly as a smartphone. Over 100 delicious recipes pre-programmed for simple Press&Go. Any skill level operator can easily create recipes offering up to 6 stages programmable cooking times, microwave power settings and instructions (written/ pictorial) for each stage.

The conneX range maximises its performance by combining power from its balanced tri-plex technology of microwave, convection and tuned impingement power. The conneX high-speed ovens speed up cooking time up to 80% faster than conventional cooking, while maintaining their energy efficiency during quick pre-heat, cool down times and standby mode. The built-in catalytic converter enables ventless cooking, making it easy to integrate into any existing commercial kitchen.

The conneX range is compact and versatile. Ideal for front-of-house open kitchen design or in a small commercial kitchen bench. Streamline your kitchen as the Merrychef conneX range is ideal for rapid cooking, toasting, grilling and reheating fresh/ frozen food. The range operates quietly without compromising consistency and performance. It maximises profits while speeding up service from kitchen to table and reduces takeaway queues.

conneX 16: The conneX 16 has the largest cavity-to-oven width ratio in the range. It is the first high-speed oven that has a 16" (405mm) cavity but is only 18" (459mm) wide. 16" pizza, open chicken paninis, vegetarian quiche, cinnamon rolls, mac & cheese in cafes, pubs, restaurants, hotels and canteen/ food counters.

The benefits
• Eliminates the need for other appliances - All in one unit to rapidly cook, toast, grill and reheat fresh or frozen food

• Built-in catalytic converter enabled ventless cooking capabilities

• Cost effective - Plug-and-play model with the self-diagnostics capability to monitor components

• Reduced queuing and service times - combining the tri-plex technology of microwave, convection and tuned impingement power to shorten cooking times

• Patented easy access front mounted air filter - easy to clean and operates with precise power control that offers consistency in high quality food on demand

Specifications
Merrychef High Speed Cook Oven

Standard Features
• All in one unit to rapidly cook, toast, grill and reheat fresh or frozen
food – eliminating need for other appliances
• Cooking up to 20 times faster than other cooking methods
• Large oven cavity to suit up to 405mm x 405mm / 16” plate size
• Fits on a 700mm bench depth
• Ventless cooking capabilities through built in catalytic converter
• High speed Technology® combines three heat technologies:
microwave, convection heat and tuned impingement
• Energy efficient with quick pre-heat, cool down times and low
energy usage in standby mode
• Easy to operate with 7” HD widescreen display with robust glass
surround
• EasyTouch 2.0 icon driven controller with unlimited storage for
multi-stage cooking profiles
• Each cooking profile offers up to 6 stages with programmable
cooking times, microwave power settings and written / pictorial
user instructions for each stage
• Self-diagnostics capability to monitor components
• Easy menu updates or data transfer via USB
• Wi-fi / ethernet connection
• Quiet operation < 48 dbA
• Cool to touch exterior allows for zero space at the sides and back
• Patented easy access front mounted air filter
• Stainless steel cavity and casework
• Easy clean cavity with sealed rounded edges

Includes
• Flat cook plate
• Guarded paddle with sides
• Full size cooking tray
• Cool down pan
• Cook plate liners (2)
• Cleaning care package, consisting of:
• 1x oven cleaner (bottle)
• 1x oven protector (bottle)

MICROWAVE POWER
Microwave settings, off or 5-100% in 1% increments
Distribution system, rotating active antennae

CONVECTED HEAT
Temperature settings OFF and from 100° to 275°C
in 1°C steps
Distribution system, Tuned Impingement

VENTILATION
Ventless certification, EPA 202 tested (8hr)
Internal catalytic filtration to limit grease and odour
emission

DIMENSIONS
Width 459 mm
Depth 684 mm
Height 619 mm
Weight 67.2 kg

PACKED DIMENSIONS
Width 620 mm
Depth 820 mm
Height 855 mm
Weight (including cleaning system) 79.2 kg

INSTALLATION REQUIREMENTS
Rear 0 mm
Right 0 mm
Left 0 mm
Top 50 mm
The item is not intended for built-in application
For precise installation instructions please refer to the
units installation manual

ELECTRICAL SUPPLY
2 phase model
400-415, 50Hz (2P+N+E)
Rated power consumption: 5.8kW
Rated current: 20A
20A 5 pin plug
Mains cable length 1.8m
All Merrychef ovens require a D type circuit
breaker for all installations

POWER OUTPUT (APPROX.)
Microwave 2.0 kW
Convected heat 3.2 kW
Combination mode 2.0** + 3.2 kW
**This is approximate microwave power output.
